Lockmaster Genuine Replacement Gearbox

This Lockmaster gearbox is a genuine replacement for the gearboxes found on Lockmaster, Goldline, Apeer and Mila Master multipoint locks.

This gearbox is a 35mm backset features a latch and deadbolt and is unsprung.

There are versions for both double spindle (92/62PZ) and single spindle (92PZ only) available.

45mm versions use a 35mm case with extended latch and deadbolt with a 10mm packer piece

Operation: Lift lever or double spindle

Latch reversal: Undo the screw in the latch to remove. Reverse and reinsert then replace screw.

• Case Height: 228mm
• Case Width: Backset + 16mm
• Centres: 92mm/62mm or 92mm only
• Backset: 35mm
• Spindle: Double 8mm
• Packaging: Supplied in singles
